5 Specifications

5.1

Electrical Data

Voltage:

6-8,5VDC

Current:

Maximum head current:Numbers of active dots * Vhead

150+/-15%

Maximum motor current:

1000mA

Power up sequence:

max. 10 msec. 10 – 90% Voltage applied

Power down sequence:

max. 10 msec. 90 – 10% Voltage applied

5.2

Mechanical Data

Dimensions: Length, width, height: 77 mm* 50 mm * max. 15 mm

Including connectors.

Vibration:

100G XYZ

Shock:

100G XYZ

5.3

Environmental Data

Operation:

Temperature:

-20°C- +85°C

Humidity :

10%-99% RH, without condensing

Storage:

Temperature:

-40°C - +85°C

Humidity:

0%-99% RH, without condensing

Transport:

Temperature:

-40°C - +85°C

Humidity:

0%-99% RH, without condensing

5.4

EMC & ESC

The printer controller is tested according to:
Emission: E-Field:

EN50081-1-1

Conducted:

EN50081-1-2

Immunity: E-field:

EN50082-1-1

Conducted transients:

EN50082-1-2

Over voltage:

EN50082-1-3

Medical equipment:

IEC601-1-2
