3.8 I/F-COM simple command set.
The following commands are use when communicating with the printer
controller. All other commands is ignored
3.8.1 Small Font
[Name] Small Font (8x12)
[Format] ASCII NUL
Hex 00
Decimal 0
[Description] Chooses small font from the current print position.
3.8.2 Low Font
[Name] Low Font (16x12)
[Format] ASCII SOH
Hex 01
Decimal 1
[Description] Chooses low font from the current print position.
3.8.3 Narrow Font
[Name] Narrow Font (8x28)
[Format] ASCII STX
Hex 02
Decimal 2
[Description] Chooses narrow font from the current print position.
3.8.4 Normal Font
[Name] Normal Font (16x28)
[Format] ASCII ETX
Hex 03
Decimal 3
[Description] Chooses normal font from the current print position.
This is the default font after power up or reset.
3.8.5 Wide Font
[Name] Wide Font (32x28)
[Format] ASCII EOT
