6.2.6 Checking the LUNs
The VMware Infrastructure Client is used to login to VMware ESX and check the LUNs.
1 Select the [Configuration] tab on VMware Infrastructure Client, and select the target iSCSI Adapter.
2 Click [Rescan...].
The LUNs are displayed under the SCSI Target 0 in the "Details" field. In this example,
[Path:vmhba32:0:0] is displayed as follows:
If LUNs are added while VMware ESX is running (LUNs are recognized dynamically), added LUNs
should be recognized by performing the VMware Infrastructure Client "Rescan" operation after the
LUN has been added to an Affinity Group.
3 Check the multipath. Right-click the [Path:vmhba32:0:0] described in Step 2 , and select "Manage
Paths".
When paths are configured with multipath, multiple paths are displayed in the "Path" field.
