6.2.4
Setting the Software Initiator
Enable Software Initiator in VMware ESX.
1
Select the [Configuration] tab on VMware Infrastructure Client and click [Storage Adapters].
2
Select the target iSCSI Software Adapter and click [Properties].
3
Click [Configure] on the [General] tab.
4
Select the [Status-Enabled] checkbox and click the [OK] button.
5
Confirm that the [Enabled] checkbox is selected under "Status" on the [General] tab and click [Config-
ure] again.
6
Confirm that the iSCSI name is displayed as follows and click the [Cancel] button.
7
Select the [Dynamic Discovery] tab and click the [Add] button.
8
Enter the IP address for the iSCSI port of the connected ETERNUS DX Disk storage system as the iSCSI
server IP address, confirm that the port is set to "Port 3260" (default), and click the [OK] button.
