4.3 SCSI Commands
C156-E224-01EN 4-17
(2) Flexible disk page
Table 4.18 Flexible disk page
Bit
Byte
7 6 5 4 3 2 1 0
0 0 0 Page Code (05h)
1 Page Length (1Eh)
2-3 Transfer Rate
4 Number of Heads
5 Sectors per Track
6-7 Data Bytes per Sector
8-9 Number of Cylinders
10-19 Reserved
20 Motor off Delay
21-27 Reserved
28-29 Medium Rotation Rate
30-31 Reserved
The Flexible disk page is only supported for compatibility of device drivers.
Device drivers should not use this page to guarantee the logical compatibility of
media.
The unit of Transfer Rate is kbps.
Number of Heads, Sectors per Track, and Number of Cylinders define logical
values, and do not indicate physical values. If a device driver or application uses
these values, logical compatibility of media is not guaranteed.
Data Bytes per Sector defines block length (200h or 800h).
Motor off Delay defines the duration after which the motor is instructed to stop.
FFh indicates that the motor is not instructed to stop.
Medium Rotation Rate defines revolutions per minute (rpm).
