2 installation direction – FUJITSU MCJ3230SS User Manual
Page 53
3.2 Mounting Requirements
C156-E224-01EN
3-7
3.2.2 Installation direction
Figure 3.4 shows the permissible installation directions for this drive. The
mounting angle tolerance must be within -5 to 10 from the horizontal. (-) shows
that the insertion faces below.
Eject button / Busy LED
Disk insertion slot
Manual eject hole
Figure 3.4 Installation directions
• Horizontal
• Vertical
(Two orientations)
