3.8 Cable Connections
C156-E224-01EN 3-25
3.8 Cable Connections
Use the following cables to connect the drive to the system. See Subsection 3.4
for details on the connector positions and cable requirements.
• Power supply cable
• SCSI interface cable
• DC ground cable (if required)
The general procedure for cable connection and notes on connecting cables are
given below. Pay attention to the insertion direction of each cable connector.
•
Make sure that the system power is off.
•
Do not connect or disconnect any cable when the power is on.
1) Connect the DC ground cable (only if required to decrease ground noise).
2) Connect the power cables.
3) Connect the SCSI interface cable.
4) After each cable connector is connected, secure the cable so that the cable
does not touch the drive or the parts on the PCA or obstruct the flow of
cooling air in the system cabinet.
