Operation and Cleaning
5-6 C156-E224-01EN
5.2 Cleaning Drive
When a dust or smoke of cigarette is stained to the lens actuator, a performance of
whole drive may be down. Clean the lens actuator periodically using following
head cleaner.
Note:
Cleaning period differs depending on the installation condition. Usually,
cleaning period is once a three months.
Table 5.1 Head cleaner
Part name Product number Order number
Head cleaner 020470 CA90002-C980
(1) Cleaning method
Clean the head actuator with following method.
1. Turn on the power of the drive.
2. Insert the head cleaner.
3. When the head cleaner is automatically loaded, the optical head positioner
moves back and forth and the cleaning brush mounted on the head cleaner
cleans the object lens.
4. When the cleaning is finished, the head cleaner is automatically unloaded.
(cleaning time: 15 seconds)
Device Damage: Be sure to use the dedicated head cleaner
described above.
Check the cleaning brush state by opening the shutter of the head
cleaner. If the tip of brush is open, use new head cleaner.
