FS-8700-41 Simplex 4100 Driver Manual Page 5 of 48
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
2 DRIVER SCOPE OF SUPPLY
2.1 Supplied by FieldServer Technologies for this driver
FieldServer Technologies Part # Description
FS-8917-16
RJ45 to terminal connector cable. (4020 and 4100 Panels)
FS-8917-07 Ethernet cable with 25 pin male connector. (4100u Panels)
SPA59132 RS-485 connection adapter
2.2 Provided by Supplier of 3 rd Party Equipment
To enable the 4100 Protocol, the 4100 system supplied by the user, must have a free RS-232 port dedicated for use
with the computer device. In most cases, this is not included in the base configuration of the product provided by
Simplex Time Recorder Company, and must be added as a sales option. All 4100 systems limit the number of
computer ports active at one time in a system. To determine the limit for the specific product configuration, refer
to the product specifications, or contact a Simplex sales representative.
