FS-8700-41 Simplex 4100 Driver Manual Page 11 of 48
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
5.2 Client Side Node Parameters
Section Title
Nodes
Column Title
Function Legal Values
Node_Name Provide name for Node Up to 32 alphanumeric characters
Node_ID n/a
This parameter is IGNORED. Keywords used to define the
card-sub-point (c-p-s) are described in Appendix A.1
Protocol Specify protocol used Sim4100
Port
Specify which port the device is
connected to the FieldServer
P1-P8, R1-R2
PLC_Type*
4020/4100 - panels with firmware
version 9x or earlier.
4100U – panels with firmware
version 10x or later.
4100, 4020, 4100U
Node_Option*
Specify the point status data
format. Refer to Appendix A.1.1
State_Store, Bit_Store
Example
// Client Side Nodes
Nodes
Node_Name , PLC_Type , Protocol , Connection
Device1 , 4100U
, Sim4100 , P1
