Appendix A.4.4. Acknowledge All Points
The ackall function can be used to ack all points or all points that are in a particular state. Each time the driver uses this Map Descriptor, it checks the data in the Data
Array. If a location is non-zero then the appropriate Ack message is sent to the panel.
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , sim4100_func , Scan_Interval , Length
AckAll_Mapdesc
, DA_ACKALL , 0 , Wrbx , Node_A , AckAll , 1.0s , 6
The 1st element of the Data Array is used to trigger the ack all
2nd – ack A Primary Abnormal State
3rd – ack
F Fire alarm
4th – ack P Priority 2
5th – ack S Supervisory
6th – ack T Trouble
Set the array element to 1 to initiate the command. The FieldServer clears the value on completion
Appendix A.4.5. Acknowledge a specific point
One Map Descriptor is required for each c-p-s combination requiring specific acknowledgements. The driver checks the array location corresponding to the Map
Descriptor. If the value is non-zero then an ack message is sent. The value is used to determine what kind of ack is sent.
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Length , Scan_Interval , sim4100_Func , Sim4100_Card , Sim4100_Point , Sim4100_Sub
Ack_mapdesc1 , DA_ACK , 0 , Wrbx , Node_A , 1 , 1.0s , Ack , 1 , 2 , 3
Ack_Mapdesc2 , DA_ACK , 1 , Wrbx , Node_A , 1 , 1.0s , Ack , 1 , 2 , 4
Bit 0: F - Fire Alarm Panel
Bit 1: P - Priority 2 alarm state
Bit 2: T - Trouble State
Bit 3: S - Supervisory State
Bit 4: U - Utility Monitor
Bit 5: C - Control State
Bit 6: D - Disable Trouble State
Bit 7: A - Primary Point
The function is Wrbx, the message is only sent when
the value is updated.
