FS-8700-41 Simplex 4100 Driver Manual Page 27 of 48
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
Appendix A.4.9. Read Analog Psuedo P oints
Use the Sim4100_func = 'value' to read the values from the analog pseudo points. Refer to Appendix C.4.2 for a list of the analog pseudo points.
// Analog Psuedo points
// Map Descriptor
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Sim4100_Func , Sim4100_Card , Sim4100_Point , Sim4100_Sub , Protocol , Length
# Fire Alarms , DA_C_144 , 0 , Rdbc , Simplex_01 , value , 144 , 0 , 0 , sim4100 , 1
# Supervisory Alarms , DA_C_144 , 1 , Rdbc , Simplex_01 , value , 144 , 1 , 0 , sim4100 , 1
# Troubles , DA_C_144 , 2 , Rdbc , Simplex_01 , value , 144 , 2 , 0 , sim4100 , 1
Excessively Dirty Sensors , DA_C_144 , 3 , Rdbc , Simplex_01 , value , 144 , 115 , 0 , sim4100 , 1
Dirty Sensors , DA_C_144 , 4 , Rdbc , Simplex_01 , value , 144 , 116 , 0 , sim4100 , 1
Almost Dirty Sensors , DA_C_144 , 5 , Rdbc , Simplex_01 , value , 144 , 117 , 0 , sim4100 , 1
