33
BALL
FIGURE 15
93
UPPER
CABLE
SLOT
11
RIGHT
TOP
CROSS
FRAME
76
PULLEY
51
3/8” x 2”
HEX BOLT
62
3/8”
WASHER
46
13mm
BUSHING
67
3/8”
LOCKNUT
2
RIGHT
OBLIQUE
FRAME 40
DOUBLE
PULLEY
BRACKET
“B”
92
BUTTERFLY
CABLE
27
RIGHT
ADJUSTABLE
PLATE
29
LEFT
ADJUSTABLE
PLATE
69
M8
LOCKNUT
BALL
SLOT
SLOT
39
DOUBLE
PULLEY
BRACKET
“A”
48
M8 x 25mm
HEX BOLT
32
PIVOT
PULLEY
BRACKET
64
M8
WASHER
DETAIL
93
UPPER
CABLE
92
BUTTERFLY
CABLE
