Parts list – Fitness Quest Brutus 655 User Manual
Page 10
10
Parts List
Item
Q’ty
Part Name
1
1
Right Base Beam
2
1
Right Oblique Frame
3
1
Right Vertical Frame
4
1
Left Oblique Frame
5
1
Left Vertical Frame
6
1
Left Base Beam
7
1
Center Base Tube “A”
8
1
Center Base Tube “B”
9
4
Guide Rod
10
1
Top Cross Frame
11
1
Right Top Cross Frame
12
1
Left Top Cross Frame
13
1
Right Seat Cushion Frame
14
1
Leg Extension Frame
15
1
Left Seat Cushion Frame
16
2
Connector Tube
17
2
Foam Rod
18
2
Seat Cushion
19
1
Right Press Arm
20
1
Right Bench Press Frame
21
1
Adjust Tube
22
1
Foot Plate
23
1
Leg Press Support
24
1
Safety Clasp
25
1
Butterfly Extension
26
2
Handle
27
1
Right Adjustable Plate
28
1
Right Butterfly Arm
29
1
Left Adjustable Plate
30
1
Left Butterfly Arm
31
1
Right Backrest Cushion
32
2
Pivot Pulley Bracket
33
1
Left Bench Press Frame
34
1
Left Press Arm
35
1
Stop Rod
36
2
Shroud
37
1
Lat Bar
38
1
Curl Bar
39
1
Double Pulley Bracket “A”
40
1
Double Pulley Bracket “B”
41
1
Left Backrest Cushion
42
1
Weight Selection Rod “A”
43
1
Weight Selection Rod “B”
44
1
Waist Band
45
1
Ankle Strap
46
12
13mm Bushing
47
3
M10 x 25mm Screw
48
3
M8 x 25mm Hex Bolt
Item
Q’ty
Part Name
49
8
M8 x 15mm Hex Bolt
50
18
3/8” x 3/4” Hex Bolt
51
15
3/8” x 2” Hex Bolt
52
4
M8 x 63mm Hex Bolt
53
7
3/8” x 2-5/8” Hex Bolt
54
25
3/8” x 3” Hex Bolt
55
1
Press Cable
56
3
3/8” x 3-1/2” Hex Bolt
57
5
3/8” x 4-1/2” Hex Bolt
58
1
3/8” x 5-1/8” Hex Bolt
59
1
3/8” x 6-1/8” Hex Bolt
60
1
5/8” x 5-3/4” Shaft Bar
61
1
5/8” x 7-3/4” Shaft Bar
62
150
3/8” Washer
63
2
3/8” Big Washer
64
22
M8 Washer
65
6
5/8” Washer
66
6
5/8” Locknut
67
66
3/8” Locknut
68
1
Squat Cable
69
5
M8 Locknut
70
16
3/4” Copper Bushing
71
18
2” Square End Plug
72
4
2” Square End Cap
73
8
1” x 2” End Plug
74
10
1” Round End Plug
75
2
2” Round End Plug
76
32
Pulley
77
2
Top Plate
78
2
7/16” Allen Cap Screw
79
33
Weight
80
2
Press Bar Pin
81
3
2” Square Rubber Bumper
82
4
Rubber Donut
83
4
Foam Roll
84
2
Long Foam Grip
85
2
Short Foam Grip
86
6
Hand Grip
87
4
Plastic Bushing “A”
88
2
Plastic Bushing “B”
89
2
Pop Pin
90
8
Chain Hook
91
3
Chain
92
1
Butterfly Cable
93
1
Upper Cable
94
1
Leg Cable
