Fitness Quest Brutus 655 - Manual (Page 25)

25
FIGURE 10
32
PIVOT
PULLEY
BRACKET
2
RIGHT
OBLIQUE
FRAME
52
M8 x 63mm
HEX BOLT
64
M8
WASHER
69
M8
LOCKNUT
76
PULLEY
51
3/8” x 2”
HEX BOLT
62
3/8”
WASHER
67
3/8”
LOCKNUT
32
PIVOT
PULLEY
BRACKET
64
M8
WASHER
76
PULLEY
71
2”
SQUARE
END PLUG
25
BUTTERFLY
EXTENSION
56
3/8” x 3-1/2”
HEX BOLT
62
3/8”
WASHER
62
3/8”
WASHER
67
3/8”
LOCKNUT
67
3/8”
LOCKNUT
26
HANDLE
28
RIGHT
BUTTERFLY
ARM
30
LEFT
BUTTERFLY
ARM
66
5/8”
LOCKNUT
65
5/8”
WASHER
29
LEFT
ADJUSTABLE
PLATE
27
RIGHT
ADJUSTABLE
PLATE
70
3/4”
BUSHING
86
HAND
GRIP
26
HANDLE
74
1”
ROUND
END PLUG
87
PLASTIC
BUSHING
“A”
48
M8 x 25mm
HEX BOLT
75
2”
ROUND
END PLUG 89
POP
PIN
86
HAND
GRIP
63
3/8” BIG
WASHER
65
5/8”
WASHER
