1. RADAR OPERATION
1-12
1.8 Choosing the Display Mode
This radar has the following display modes:
• IMO, A type: Radar, Radar + Plotter
• B, C, W type: Radar, Radar + Plotter, Plotter
Choose a display mode as below. Note that a display mode cannot be chosen
when the menu is open.
1. Roll the trackball to place the arrow in the DISPLAY MODE box at the top of
the screen.
DISPLAY
XX*
* XX = display mode
DISPLAY MODE box
2. Push the left button to choose appropriate mode:
RADAR: Radar picture
+PLOTTER: Radar picture + plotter picture (incl. chart)
PLOTTER: Plotter
