FURUNO
FAR-2157/2167DS
SP - 3
E3522S01A-M
FAR-2167DS 220/380VAC: 3/1.5A, 3 phase, 50 Hz or
220/440VAC: 3/1.5A, 3 phase, 60 Hz
5.4 Antenna unit 200/220/380/440 VAC , 3 phase, 50/60 Hz
Antenna voltage input (100 kn)
Model 200 VAC, 3 φ 50 Hz,
220 VAC, 3 φ, 60 Hz
380 VAC, 3 φ, 50 Hz,
440 VAC, 3 φ, 60 Hz
FAR-2167DS 3.0 A 1.5 A
5.5 Console 115/230 VAC, 1 phase, 50/60 Hz
5.6 Transformer ( option)
For single phase RU-1803: 440 VAC, 1 phase, 50/60 Hz
For triple phase RU-5693: 110 VAC, 3 phase, 60 Hz
RU-6522: 220 VAC, 3 phase, 50 Hz
RU-5466-1: 440 VAC, 3 phase, 50 Hz
6 ENVIRONMENTAL CONDITIONS
6.1 Ambient temperature
Monitor/processor/transceiver/control/power supply unit
-15°C to +55°C
Antenna unit -25°C to +55°C (storage +70°C)
6.2 Relative humidity 95% max. at 40°C
6.3 Degree of protection
Monitor/processor/control/power supply unit IPX0
Antenna unit IPX6
6.4 Vibration IEC60945 Ed.4
7 COLOR
7.1 Monitor unit Chassis: 2.5GY5/1.5, Panel: N3.0 (fixed)
7.2 Processor/power supply unit 2.5GY5/1.5
7.3 Control unit
N3.0 (fixed)
7.4 Antenna unit N9.5 (fixed)
8 PERFORMANCE MONITOR (PM-50)
8.1 PM-30 (X-band)
8.1.1 Frequency range 9370 to 9450 MHz
8.1.2 Input power +8dBm min, +28dBm max.
8.1.3 Output power -36dBm (2 nd pulse max. output), -56dBm (2 nd pulse min. output)
8.1.4 Step levels 7.5 to 10.5 dB (1 st pulse to 2 nd pulse)
8.2 PM-50 (S-band)
8.2.1 Frequency range 3020 to 3080 MHz
8.2.2 Input power -5dBm min, +15dBm max.
8.2.3 Output power -15dBm (2 nd pulse max. output), -35dBm (2 nd pulse min. output)
8.2.4 Step levels 9.0 to 11.0 dB (1 st pulse to 2 nd pulse)
9 SWITCHING HUB (HUB-100)
9.1 Access format CSMA/CD
9.2 Switching format Store and forward
