4. AIS OPERATION

4-13

4.9.2

Past position display attributes

You may choose the number of past position points to show per plot interval and
the color of past position points.

1. Roll the trackball to choose the MENU box and then push the left button.
2. Roll the wheel to choose 4 ARP•AIS and then push the wheel or the left

button.

3. Roll the wheel to choose 7 [AIS SYMBOL] and then push the wheel or the

left button.

[AIS SYMBOL]

1 BACK
2 AIS SYMBOL COLOR

RED/GRN/BLU/YEL/
CYA/MAG/WHT

3 AIS SYMBOL SIZE

SMALL/STD/LARGE

4 ROT TAG LIMIT

000.1˚/

MIN

5 PAST POSN COLOR

RED/GRN/BLU/YEL/
CYA/MAG/WHT

6 PAST POSN POINTS

5/10

AIS SYMBOL menu

4. Roll the wheel to choose 5 PAST POSN COLOR and then push the wheel or

the left button.

5. Roll the wheel to choose color desired and then push the wheel or the left

button.

6. Roll the wheel to choose 6 PAST POSN POINTS and then push the wheel or

the left button.

7. Roll the wheel to choose 5 or 10 as appropriate and then push the wheel or

the left button.

8. Push the right button three times to close the menu.
