3. ARP OPERATION
3-33
[CUSTOMIZE•TEST]
1 BACK
2 [DATA BOX]
3 [F1]
4 [F2]
5 [F3]
6 [F4]
7 [OPERATION]
8 [TEST]
[TEST]
1 BACK
2 [SELF TEST]
3 [ARP TEST]
[ARP TEST]
1 BACK
2 ARP TEST START
NOTE:
THE DISPLAY IS
CLEARER WHEN
RUNNING ARP TEST.
RUN ARP TEST?
YES: SELECT 2 START
NO: SELECT 1 BACK
3.16 ARP Performance Test
A test program is provided for assessing overall performance of the ARP. Normal
operation is suspended and the indication “XX” appears at the bottom of the
effective display area during the test. The test may be terminated at any time.
1. Roll the trackball to choose the MENU box and then push the left button.
2. Roll the wheel to choose 9 [CUSTOMIZE•TEST] and then push the wheel or
the left button.
CUSTOMIZE•TEST menu
3. Roll the wheel to choose 8 [TEST] and then push the wheel or the left button.
TEST menu
4. Roll the wheel to choose 3 [ARP TEST].
ARP TEST menu
