1. RADAR OPERATION
1-97
In the example below, START is 130° and ANGLE is 100°.
START
(Example: 130
°) ANGLE
(Example: 100
°)
Width of sector
9. Select 5 COMBINE RANGE and push the left button.
10. Use the scrollwheel to set START and LENGTH, referring to the example below.
Spin the scrollwheel to set and push it to confirm.
• START: Set range start point.
• LENGTH: Set length of sector.
START
LENGTH
Example:
START:
01.00 nm
LENGTH: 02.00 nm
Push the right button four times to close the menu.
