86
NO
Load the documents correctly
on the ADF paper chute. Are the documents loaded correctly
on the ADF paper chute?
YES
Is the ADF closed completely?
YES
Is the interface cable connected
correctly?
NO
Remove all documents from
the ADF paper chute. Then
open and close the ADF.
NO
Connect the interface cable
correctly.
Symptom 3 The scanning does not start.
(when using the scanner on SCSI
interface)
Is the SCSI ID set correctly?
YES
NO
Set the SCSI ID correctly by
the SCSI ID switch on the
rear side of scanner.
Does the Function No. display
indicate any alarm?
NO
The scanner operation is
normal.
YES
YES
Does the alarm state remain
displayed even after the scanner
has been turned off and on again?
YES
NO
The scanner operation is
normal.
Contact the manufacturer's
authorized service center.
