fi-4530C Image Scanner Operator’s Guide 61
Chapter 4
REPLACING CONSUMABLES
This chapter describes how to replace scanner consumables.
In this chapter Windows XP screenshots are illustrated.
The screens and operations may differ slightly if the OS that you are using is not Windows XP.
Also, when FUJITSU TWAIN32 is updated the screens and operations noted in this chapter will
differ slightly.
WARNING Turn off the power and unplug the AC adapter from the
outlet before changing the scanner’s consumable
products
.
4.1 Consumable and Replacement Cycle ................................................................. 62
4.2 Replacing the Pad ASSY ...................................................................................... 67
4.3 Replacing the Pick Roller..................................................................................... 72
