4.2 Replacing the Pad ASSY
fi-4530C Image Scanner Operator’s Guide
67
REPLACING CONSUMABLES
4
4.2
Replacing the Pad ASSY
1. Remove all documents from the ADF paper chute.
2. Open the ADF cover by pushing down the ADF button.
CAUTION
Be careful, the ADF cover may close and pinch your
fingers.
The front portion
ADF button
