background image

FS-8700-97 Lutron Machine Manual

Page 8 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]

5.2

Client Side Node Parameters

Section Title
Nodes
Column Title

Function

Legal Values

Node_Name

Provide name for node

Up

to

32

alphanumeric

characters

Node_ID

The eLumen processor address. Only decimal values are
allowed: e.g. 11 hex must be entered as 17.

0-255

Protocol

Specify protocol used

eLumen

Connection

Specify which port the device is connected to the
FieldServer

P1-P8, R1-R2

Node_Type

Specifies the eLumen command and data format

Hex, Decimal


Example

// Client Side Nodes

Nodes

Node_Name , Node_ID , Protocol , Port , Node_Type
LUT_GRF6_0 , 17

, eLumen

, P1 , Hex

5.3

Client Side Map Descriptors

5.3.1 FieldServer Related Map Descriptor Parameters

Column Title

Function

Legal Values

Map_Descriptor_Name Name of this Map Descriptor

Up to 32 alphanumeric characters

Data_Array_Name

Name of Data Array where data is
to be stored in the FieldServer

One of the Data Array names specified in Section
4.

Data_Array_Offset

Starting location in Data Array

0 to (Data_Array_Lenght -1) as defined in
Section 4.

Function

Function of Client Map Descriptor

Arco, Awt, Rdbc, Passive_Client, Arcs. Refer to
Appendix A.1 for more information.
