FS-8700-97 Lutron Machine Manual

Page 13 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]

5.3.7 Map Descriptor Example 4 - Analog Output 1 (Area Machine)

A write to the Analog Output Data Array which is shared by a BACNet IP Map Descriptor will command an area to a preset scene on the Lutron eLumen panel. Scenes
range from 0 to 65535 and area numbers range from 0 to 511

BACNet IP Map Descriptor

// Client Side Map Descriptors

Map_Descriptors

Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name

, Data_Type , Object_ID , Length , Relinquish_Default

SMD000_AO

, Analog_Output

, 0

, Passive

, Virtual_BCU_11 , AO

, 1

, 512

, 0

Lutron Machine Map Descriptor

// Client Side Map Descriptors

Map_Descriptors

Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , Grafik_Command

, Area , Length

Sel_scene_0

, Analog_Output

, 0

, Awt

, LUT_GRF6_0 , Sel_Scene_In_Area , 0

, 512

The area field must be used to indicate the start area number that will be associated with the first element of the Data Array specified under Data_Array_Name. Area
numbers increase with the Length field in association with increasing offset into the Data Array.
