Pinouts – FieldServer Lutron Machine FS-8700-97 User Manual
Page 5
FS-8700-97 Lutron Machine Manual
Page 5 of 24
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
3.1
Pinouts
Function From
To
Color
RX
RJ45-01 DB9F-02
Red
CTS
DB9M-08 White
GND
RJ45-04 DB9F-05
Black
RTS
DB9F-07
Brown
TX
RJ45-08 DB9M-03 Green
