FS-8700-97 Lutron Machine Manual

Page 16 of 24

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]

The Multi_Scripts_Length field is used to indicate the maximum size of the Data Array specified under
Data_Array_Name. One Map Descriptor per object must be defined with a Multi_Scripts_Length value of 1 or
greater.

The script numbers per BACNet object element need to be preloaded into the Data Arrays defined under
“DA_Lut_List”.

Analog Output2 Settings Setup

All values are in decimal ( 0 - 65535 )

Specify up to 10 scripts for each Object ID by editing Preload_Data_Value

Preloads

Data_Array_Name

, Preload_Data_Format , Preload_Data_Value , Location


// Analog Output2 Object ID 513
Scr_lst_AO2_512

, Uint16

, 100

, 0

Scr_lst_AO2_512

, Uint16

, 200

, 1

Scr_lst_AO2_512

, Uint16

, 300

, 2

Scr_lst_AO2_512

, Uint16

, 400

, 3

Scr_lst_AO2_512

, Uint16

, 500

, 4

Scr_lst_AO2_512

, Uint16

, 600

, 5

Scr_lst_AO2_512

, Uint16

, 700

, 6

Scr_lst_AO2_512

, Uint16

, 800

, 7

Scr_lst_AO2_512

, Uint16

, 900

, 8

Scr_lst_AO2_512

, Uint16

, 65000

, 9

// Analog Output2 Object ID 514

Scr_lst_AO2_513

, Uint16

, 101

, 0

Scr_lst_AO2_513

, Uint16

, 201

, 1

Scr_lst_AO2_513

, Uint16

, 301

, 2

Scr_lst_AO2_513

, Uint16

, 401

, 3

Scr_lst_AO2_513

, Uint16

, 501

, 4

Scr_lst_AO2_513

, Uint16

, 601

, 5

Scr_lst_AO2_513

, Uint16

, 701

, 6

Scr_lst_AO2_513

, Uint16

, 801

, 7

Scr_lst_AO2_513

, Uint16

, 901

, 8

Scr_lst_AO2_513

, Uint16

, 65001

, 9
