1 LUTRON MACHINE DESCRIPTION
The Lutron Machine driver allows the FieldServer to transfer data to and from devices over RS-232 using Lutron
eLumen protocol. The FieldServer can emulate either a Server or Client, although the Lutron Machine driver is
only available in Client configuration. Server drivers are for FieldServer testing purposes only.
Max Nodes Supported
FieldServer Mode Nodes Comments
Client 1
Only one Lutron Machine driver Client node is able to be connected to a
Lutron eLumen panel.
Server 1 One BACNet IP node provides an interface to the Lutron eLumen panel.
The Lutron Grafik Machine Zone/Area Machine driver, hereafter simply referred to as the Lutron Machine driver,
provides a BACNet IP interface to a Lutron eLumen panel. The driver can be configured to represent zones or
areas as used in the Lutron eLumen panel. The FieldServer acts as both Client and Server to provide BACNet
objects to an external BACNet Client. In Server mode, the FieldServer collects data from the eLumen panel and
holds the data ready for reads from an external BACNet Client. In Client mode, the FieldServer executes pre-
defined commands on the eLumen panel, for example, running scripts.
2 DRIVER SCOPE OF SUPPLY
2.1 Supplied by FieldServer Technologies for this driver
FieldServer Technologies PART # Description
FS-8915-10
UTP cable (7 foot) for RS-232 use
FS-8917-03 RJ45 to DB9F connector adapter
2.2 Provided by the Supplier of 3 rd Party Equipment
2.2.1 Hardware
Part # Description
Lutron eLumen Panel
2.2.2 Required 3 r d Party Software
An external BACnet IP Client to interface to the Lutron Machine on the FieldServer.
2.2.3 Required 3 r d Party Configuration
BACnet IP Client must be set up to access FieldServer over the network.
