Frymaster 17EC - Manual (Page 93)

7-29
ITEM PART # COMPONENT
1 810-1208 Valve, Water Pressure Regulator
2 806-7551 Valve Assembly, Solenoid
3 813-0513 Faucet, Double Jointed (with no cutoff valve)
4 910-2513 Tubing, Solenoid Valve to Cookpot
5 812-1292 Tubing, Regulator Valve to Right Solenoid Valve (used in double units)
6 812-1293 Tubing, Regulator Valve to Left Solenoid Valve (used in double units)
7 910-5149 Tubing, Solenoid Valve to Faucet
8 910-8011 Tubing, Regulator Valve to Solenoid Valve (units with basket lifts only)
9 910-8012 Tubing, Solenoid Valve to Faucet (units with basket lifts only)
10 813-0507 Coupling, ¼-inch NPT Brass
11 810-0907 Compression Fitting, ⅜-inch NPT to Tubing 90º Elbow
12 900-2915 Bracket, Pressure Regulator Valve (used in double units)
13 900-2917 Brace, Water Inlet (used in double units)
14 900-7991 Bracket, Pressure Regulator Valve (units with basket lifts only)
15 900-2916 Bracket, Pressure Regulator Valve (units without basket lifts only)
16 900-1905 Bracket, Solenoid Valve (units without basket lifts only)
17 809-0454 Nut, ½-inch Conduit
18 813-0472 Nipple, ¼-inch NPT x 2.5-inch
19 813-0471 Nipple, ¼-inch NPT x 1.5-inch
20 813-0450 Nipple, ¼-inch NPT x 2.0-inch
21 813-0448 Elbow, 90º ¼-inch NPT
22 810-1025 Compression Fitting, ¼-inch NPT to Tubing Straight
23 813-0495 Tee, ¼-inch NPT Male Branch to ¼-inch NPT Female
