7-27
ITEM
PART #
COMPONENT
1
807-0680
Transformer, 208-240VAC/24VAC, 50/60Hz, 43VA
2
809-0112
Screw, 8-32 x 1¼-inch, Slotted Truss Head
3
809-0247
Nut, 8-32 Hex Keps
4
807-0979
Transformer, 208-240VAC/12VAC, 50/60Hz, 20VA (for Basket Lift)
5
809-0104
Screw, 8-32 x ½-inch Slotted Hex Washer Head
6
809-0050
Nut, 8-32 Hex
7
810-1202
Contactor, 3-pole, 600V, 40 Amp
8
807-2465
Power Block
9
807-0070
Terminal, Ground Lug
10
807-2136
Connector, 6-pin High Amp Female (2 x 3)
11
807-0875
Connector, 15-pin Female (3 x 5)
12
900-5000
Back, Contactor Box
13
900-5001
Contactor Box
14
900-5027
Brace, Contactor Box Front
15
900-5028
Brace, Contactor Box Rear
16
900-0289
Bracket, Contactor Box (used with Moisture Shield [Item 27, Page 22])
17
809-0360
Screw, 8-32 x ⅜-inch Slotted Hex Washer Head Drill Point
18
809-0434
Screw, 8-32 x ⅜-inch Hex Washer Head Machine
19
900-5150
Cover, Contactor Box
20
807-0804
Connector, 15-pin Male (3 x 5)
21
807-0160
Connector, 12-pin Male (3 x 4)
22
807-0159
Connector, 12-pin Female (3 x 4)
23
807-2137
Connector, 9-pin Male (3 x 3)
24
807-2138
Connector, 9-pin Female (3 x 3)
25
807-2135
Connector, 6-pin High Amp Male (2 x 3)
26
807-0184
Connector, 6-pin Male (1 x 6)
27
807-3075
Connector, 5-pin Male (1 x 5)
28
807-2078
Connector, 4-pin Male (1 x 4)
29
806-9299
Harness, Contactor Box Internal (15-pin female connector with 10 leads)
30
806-9095
Harness, Contactor Box External (15-pin male connector with 6 leads)
31
806-9309
Harness, EWBS Computer (15-pin male connector with 7 leads)
32
806-8808
Harness, Contactor Box Internal (15-pin female connector with 6 leads)
33
806-9308
Harness, EWBS IFB to Components (12-pin male connector with 3 leads)
34
106-0156
Harness, Element to Contactor (6-pin female connector with 6 leads)
*
806-8807
Harness, Element to Contactor (9-pin female connector with 6 leads)
35
806-9096
Harness, ESW Interface Board (6-pin male connector with 6 leads)
36
806-9305
Harness, EWBS Basket Lift (5-pin male connector with 4 leads)
37
806-9097
Harness, ESW/EWBS w/o Basket Lift (4-pin male connector with 4 leads)
* Not illustrated.
