6-25
ITEM PART # COMPONENT
1 823-2937SP Cookpot Assembly (for 17EMCS (McDonald’s), use 823-3827SP)
2 823-1994SP Rinse Tank Assembly
3 806-7552SP Water Level Sensor Assembly
4 900-5045 Retainer, Cookpot Front Insulation
* 816-0152 Insulation, Cookpot Front (behind Item 4)
5 900-1762 Retainer, Insulation
6 826-1376 Nut, 10-32 Hex Head Keps (Pkg of 10)
7 807-3333 Probe, Temperature
8 210-0681 Guard, Temperature Probe
9 807-2466 Thermostat, High-Limit
10 807-3814 Element, 208V 8.625kW (for 230V, use 807-3815; for 240V, use 807-3816)
11 810-0976 Nozzle
12 N/A Guard, Water Level Sensor (part discontinued; no longer used)
13 809-0047 Nut, ¼-20 Cap (secures Item 12 on units built before February 2001)
14 813-0451 Nipple, 1 ¼-inch NPT x 12-inch Chromed Brass
15 813-0453 Nut, 1 ¼-inch NPT Chromed Stainless Steel Slip
16 813-0148 Nipple, 1 ¼-inch NPT x 6 ¼-inch NPT
17 813-0070 Elbow, 1 ¼-inch NPT 90º
18 813-0400 Nipple, 1 ¼-inch NPT x 2-inch
* 813-0391 Nipple, 1 ¼-inch NPT Close (connects cookpot drain valve and Item 19)
19 813-0394 Tee, 1 ¼-inch NPT
20 813-0146 Nipple, 1 ¼-inch NPT x 4 ¼-inch
21 813-0518 Nipple, 1 ¼-inch NPT x 4-inch
22 813-0395 Union, 1 ¼-inch NPT
23 813-0144 Nipple, 1 ¼-inch NPT x 3 ¾-inch
24 813-0554 Nipple, 1 ¼-inch NPT x 7-inch
25 814-0047 Sleeve, Red Drain Valve Handle
26 910-9527 Handle, Drain Valve
27 810-1825 Valve, 1 ¼-inch NPT Drain
28 823-2022 Strainer
29 910-2042 Clamp, Element
30 910-5214 Support, Element
31 910-2097 Bracket, High-Limit
32 809-0769 Screw, #8 X ⅜-inch S/S Hex Washer Slot Head
* 809-0204 Washer, Teflon (fits between Item 10 and inside face of Cookpot)
* 809-0063 Nut, ⅜-16 Jam (secures Drain Valve Handle to Drain Valve)
* Not illustrated.
