6-21
ITEM PART # COMPONENT
1 823-2007 Arms, Basket Lift
2 910-7420 Top, Basket Lift Enclosure
3 911-7417 Side, Basket Lift Enclosure Right
4 912-7417 Side, Basket Lift Enclosure Left
5 900-7421 Support, Basket Lift Rod Bushing
6 826-1363 Screw, 8-32 x ½-inch Slotted Truss Head (Pkg of 25)
7 902-1927 Bracket, Left Basket Lift Roller
8 901-1927 Bracket, Right Basket Lift Roller
9 809-0247 Nut, 8-32 Hex Keps
10 809-0508 Bolt, ¼ -20 x 1 ¼-inch Hex Head SS
11 810-0194 Roller, Basket Lift
12 809-0047 Nut, ¼-20 SS Hex Cap
13 809-0082 Ring, ¾-inch Truarc
14 810-0045 Bushing, Basket Lift Rod
15 807-0108 Motor, 240VAC Basket Lift
16 900-7416 Mount, Basket Lift Motor
17 809-0113 Screw, 8-32 x 1 ½-inch Slotted Truss Head
18 809-0050 Nut, 8-32 Hex
19 812-0138 Insulation, Motor Mount (Fishpaper)
20 807-0240 Microswitch
21 809-0097 Screw, 6-32 x 1-inch Slotted Truss Head
22 826-1358 Nut, 6-32 Hex (Pkg of 25)
23 810-0052 Cam (Bellcrank), Basket Lift
24 809-0194 Washer, 5/16-inch SAE Flat
25 809-0196 Washer, ⅜-inch SAE Flat
26 809-0063 Nut, Jam 3/8-16 Hex
27 826-1381 Washer, ½-inch ID x ⅞-inch OD Nylatron Flat (Pkg of 10)
28 910-4525 Bar (Link), Basket Lift Synchronizing
29 809-0155 Screw, 5/16-18 x ⅝-inch Leveling
30 826-1370 Screw, ¼-20 x 1 ¼-inch Slotted Round Head (Pkg of 10)
31 809-0076 Nut, ¼-20 x ¾-inch Expansion
32 920-6076 Link, Basket Lift
33 810-0170 Pin, ¼-inch x ⅝-inch Spring Dowel
34 810-0192 Rod, 19 ⅝-inch Basket Lift
35 809-0127 Screw, ¼-20 x ½-inch Slotted Round Head
36 809-0719 Screw, #10 x ½-inch 410SS
37 900-7418 Panel, Upper Basket Lift Rear
38 900-7419 Panel, Lower Basket Lift Rear
39 807-0124 Bushing, Heyco
40 810-0220 Spacer, Tubular, .493-inch OD
