6-28
1
2
3
5
6 7 8
9
10
11
12
13
14
4
4
ITEM PART # COMPONENT
1 810-0907 Elbow, ⅜-inch NPT Compression
2 910-2513 Tubing, Solenoid Valve to Cookpot ⅜-inch Stainless Steel
3 806-5565 Valve Assembly, 24VAC 60Hz Solenoid
4 813-0302 Elbow, ⅜-inch Tube to ¼-inch NPT 90º Brass Male
5 813-0472 Nipple, ¼-inch NPT x 2.5-inch Brass
6 900-1905 Mount, Solenoid Valve
7 813-0022 Nipple, ½-inch NPT x Close
8 809-0454 Nut, ½-inch Conduit
9 810-1208 Valve, Pressure Regulator
10 900-1898 Tube, ⅜-inch Water Line
11 813-0449 Tee, ¼-inch NPT Brass
12 813-0448 Elbow, ¼-inch NPT 90º Brass
13 813-0473 Nipple, ¼-inch NPT x 4-inch Brass
14 813-0412 Faucet, Double Jointed Pantry
* 826-1132 Kit, Faucet Repair (contains two valve assemblies)
* Not illustrated.
WATER SUPPLY SYSTEM COMPONENTS
