XG2600 Hardware Guide
Chapter 2 Installation
Installation of the switch
32
Caution
• Do not install PSUs to face the front side of the rack. They do not work properly.
• Before installing the switch in the rack, check if the airflow direction of the fans is correct. If the
air flows incorrectly, it may cause failure to the switch
The diagram below shows in which slots PSUs need to be installed and airflow direction of the fans.
: Installing
–
: not installing
The LED lights in a correct configuration as follows:
–
: Unsupported because the unit is not installed
If the LED indicators are different from the above, it may be due to the incorrect configuration of PSUs and/or Fans, or
there may be failures with PSUs and/or Fans.
Power Supply Unit
Fan Unit
Switch Port Side
Switch Fan Unit Side
FAN1 Slot
FAN2 Slot
PSU1 Slot
PSU2 Slot
PSU1 Slot
PSU2 Slot
Installation
Airflow
Installation
Airflow
–
–
Intake
Intake
Switch Port Side
Power Supply Unit
Switch Fan Unit Side
Switch Port Side
Switch
Fan Unit Side
Slot 1/Slot 2
READY
CHECK
PSU1
PSU2
FAN
PSU1
PSU2
PSU1
PSU2
STATUS
OUTFLOW
POWER
Green
Off
Green
Green
Green
Green
Green
–
–
Green
Off
