XG2600 Hardware Guide
Chapter 1 Getting Started
Items in the Package, Descriptions and Functions
19
•
CD-ROM
It contains the Firmware and User Guide (in a PDF format) necessary for operating and
configuring the switch. Adobe Reader is required for viewing.
•
XG2600 Hardware Guide (with Licence Agreement)
This manual describes the hardware of the XG2600.
1.1.2
Installation of Switch: Front Access or Rear Access (User
Configured Airflow)
There are two options available to install the switch in a different direction in a rack that helps suppress heat interference,
depending on user’s requirements
•
Rear-Access Configuration (Factory Default)
The port side (SFP+ slots) is facing backward in a rack, which serves better for connecting the switch to equipment
whose port side is also located in the backside of the rack such as servers.
•
Front-Access Configuration (User Configured)
The port side (SFP+ slots) is facing forward in a rack, which serves better for connecting the switch to equipment
whose port side is facing forward such as other switches, routers, etc.
Choose either of the above to install the switch in the rack, depending on user’s requirements.
Note
• RS232C Cable is not included in the product package
• USB memory is not included in the product package
Reference See "2.2.1 Decide Switch Access Configuration" (pg.31) for the detailed instructions for installation.
