6 VLAN
73
E
6.2 Creating VLAN
Perform the following procedures to create a VLAN.
1 Log on with administrator privileges.
2 Set the port of the switch connected to the Ethernet controller to
enable send/receive of VLAN tag frames.
3 Click [Start] → [Settings] → [Control Panel] → [Intel®PROSet
Wired], and start Intel
®
PROSet.
4 Select LAN adapter to set VLAN, and right click.
A VLAN cannot be set to an adapter composing a team.
5 Click [Add VLAN].
6 Set [ID] and [Name], then click [OK].
[ID] must be the same as the set values on the switch. The available range to set is 1 to 4094.
[Name] does not need to be the same as the setting on the switch.
When the confirmation message appears, select [Yes].
7 Repeat Steps 4 through 6 to set respective VLANs.
8 Click [OK] and exit Intel
®
PROSet.
When configuring a VLAN is completed, a virtual adapter "Intel(R) Advanced Network
Services Virtual Adapter" will appear.
Upper layer protocol is bound to this virtual adapter.
You cannot bind them with the Ethernet controller that makes up a Team.
IP address is set in this virtual adapter.
9 Restart the system.
