background image

1 1Gbit/s Ethernet I/O Module

49

E

1.2

Specifications

`

A server blade installed with a 1Gbit/s Ethernet I/O Module and a server blade
installed with a 2Gbit/s FC I/O Module cannot be installed to the same chassis.

`

When a Switch Blade or a GbE Pass-Thru Blade is installed to network blade slot 3
or 4 (NET3 or 4), a FC Pass-Thru Blade cannot be installed at the same time.

Item

Specifications

Product ID

PG-LND101

Host bus
specifications

Interface

PCI-X bus Rev.1.0a, PCI bus Rev.2.3 (Compatible with logical

specifications) 64 bit/133MHz

Data transfer rate

Max. 1GB/sec. (At PCI-X bus 133MHz operation) *1

Data transfer system

Bus master, DMA

External interface

1000BASE-T Ethernet (SerDes) interface (Maximum transfer speed

at the chassis internal connection is fixed to 1Gbps)

Controller LSI

Intel(R) 82546GB, dual port

Applicable model

BX620 S2 Server Blade

*1: It varies depending on the PCI-X bus operation speed of the server blade daughter card slot. For example,

when PCI-X bus clock frequency is 100MHz, the data transfer speed of the 1Gbit/s Ethernet I/O Module is
maximum 800MB/sec (at peak).
