T
echnical Specifications
65
Signature 2.0
Signature 2.0 Processor/Tuner Specifications
Inputs:
Analog Audio:
Six Stereo pairs via RCA jacks
Digital Audio:
Four Coaxial S/P-DIF, Two Optical TosLink
External Adapter:
Six Direct Analog channels via RCA jacks
Composite Video:
Six RCA jacks
S-Video:
Two 4-pin mini DIN
IR Sensor Input:
3.5mm mono mini-plug
Outputs:
Main Audio:
Six Analog Outputs via RCA jacks (left, center, right, right surround,
left surround, subwoofer)
Main Video:
One Composite RCA jack output paralleled with
one S-Video 4-pin mini DIN
Record Audio:
Two pair (paralleled) analog via RCA jacks
Record Video:
One Composite via RCA jack paired with
one S-Video via 4-pin mini DIN
IR Sensor:
Loop-through output via 3.5mm mono mini plug
Accessory Trigger:
6 – 12 volt DC via 3.5mm mono mini plug, tip positive, 150mA maximum.
Surround Modes:
Analog:
Dolby Pro Logic, Four Movie Modes, Four Music Modes, Stereo,
Mono, Mono +
Digital:
Dolby Digital, Dolby Digital Late Night, Dolby Digital
Pro Logic, Dolby Digital Mono, DTS 5.1, DTS 4-Channel,
DTS 2-Channel, Stereo, Mono +
Preamplifier:
Frequency Response:
Front Channels (Analog Stereo): 20Hz to 50kz, ± 0.5dB
Center and Surround Channels: 20Hz to 30kHz, ± 1dB
Subwoofer Channel: 10Hz to 100Hz, ± 1dB
THD + N:
0.03%, 20Hz to 20kHz
S/N Ratio:
>–87dBr, 20Hz to 20kHz
Crosstalk:
<60dB
Input Impedance:
Audio: >10K
½
Video: 75
½
Output Impedance:
Audio: 300
½
Video: 75
½
Crossovers:
Low Pass: 3 Pole (18dB/Octave) @ 100Hz
High Pass: 3 Pole (18dB/Octave) @ 100Hz
Tone Controls:
Treble Cut: –0dB to –8dB in 2dB steps @ 10kHz shelving
Bass Boost: +0dB to +8dB in 2 steps @ 50Hz
Video Standards:
NTSC, PAL
