Illustrated Parts Catalog
1-2
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 10:55 AM
Table 1-1: Mechanical and System Components
Item Description
Spare Part Number
Mechanical Components
1
Chassis, 4U, with backplane
229198-001
2 Bezel
blank
229208-001
3 Interconnect
blank
229200-001
System Components
4
AC power supply assembly, 499 W
212398-001
5 Blower
123482-001
Boards
6
2-Port Shared Storage Module for HP StorageWorks Modular Smart Array 500
system
229205-001
7 Controller
229202-001
8
Power button/LED assembly
229201-001
9
Cache module, DIMM, SDRAM, 128 MB, with battery *
171387-001
Miscellaneous
10
AC power cord *
187335-001
11
Return kit *
249670-001
Options
12
4-Port Shared Storage Module for MSA500 system *
300867-001
13
DC power supply, -48 V *
243791-001
14
Cache module, DIMM, SDRAM, 256 MB, with battery *
262012-001
15
Universal hard drive, 1-inch *
177986-001
16
Universal Hot-Plug Tape drives *
a) AIT, 50/100-GB capacity
b) AIT, 35/70-GB capacity
c) DDS-4, 20/40-GB capacity
190716-001
218575-002
230203-001
17
M-Series Rack Rail option *
314635-001
* Not shown
