Specifications
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide 5-3
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 11:04 AM
Hot-Plug AC Power Supply
Table 5-4: Hot-Plug Power Supply Specifications
Specification Value
Height 12.7 cm (4.5 in)
Width 15.9 cm (6.25 in)
Depth 24.1 cm (9.5 in)
Weight 2.9 kg (6.4 lb)
Note: The MSA500 system power supply specifications are calculated
without the blower.
Hot-Plug DC Power Supply
Table 5-5: Hot-Plug DC Power Supply Specifications
Specification Value
Voltage
Nominal input voltage -48 or 48 VDC
Maximum input voltage 75 VDC
Operating voltage range 36 to 72 VDC
Ripple/Noise 100 mV PARD*
Overshoot Must remain within regulation limits during startup or shutdown
Current
Max steady state input current 13.2 A
In-rush current 70 A
Input over-current Customer must provide fusing for facility DC feeds that protect the
system from catastrophic over-current within 20 uS. Fuse should
sustain all in-rush and operating currents.
Max input current slew rate 1A/uS
Max rated power 499 W
*Periodic and random noise (PARD). Maximum allowable peak-to-peak ripple and noise (as measured at the load on
any output channel). The ripple and noise is measured over a 20 Hz to 100 MHz frequency band.
