Controller components, Controller display, Controller components -8 – HP StorageWorks Modular Smart Array 500 System User Manual
Page 36: Controller display -8
Component Identification
4-8
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 11:00 AM
Controller Components
Controller Display
Each MSA500 controller has an LCD display for informational and error messages.
1
2
3
4
5
Table 4-8: Controller Display
Item Description
1 Display
2 Left
button
3 Up
button
4 Right
button
5 Down
button
