Component Identification
4-6
HP StorageWorks Modular Smart Array 500 System Maintenance and Service Guide
HP CONFIDENTIAL Codename: Aurora Part Number: 251850-004 Last Saved On: 9/19/03 11:00 AM
4-Port Shared Storage Module Components
2
1
4
3
Table 4-6: 4-Port Shared Storage Module Components
Item Connector
Description
Bus
1
SCSI port connector A1
2
SCSI port connector A2
A
3
SCSI port connector B1
4
SCSI port connector B2
B
