M O T U A U D I O S E T U P
38
Figure 5-2: The Mac OS X sound preferences let you use the Track16
for general stereo audio input and output for your Mac.
The Default Stereo Input and Default Stereo Output
settings in MOTU Audio Setup (Figure 5-1 on
page 36) let you specify the stereo input and output
on the Track16 to be used when it is chosen as the
audio I/O device in the system preferences.
Under Mac OS X 10.6 (Snow Leopard) or later, you
can use the Mac’s volume control, such as the
Output volume slider shown in Figure 5-2, or the
volume keys on your Mac’s keyboard, to control
the output level.
Phones Assign
The Phones Assign setting lets you choose what you
will hear from the headphone jack. Choose Main
Out 1-2 if you’d like the headphone output to match
the main outs. Choose Phones 1-2 if you would like
the headphones to serve as their own independent
output, which you can access as an independent
output destination in your host audio software and
as an output destination for the four on-board
CueMix FX mix busses.
Optical input/output
The Optical input and Optical output settings let
you choose between 8-channel ADAT optical
(‘lightpipe’) and stereo S/PDIF optical
(‘TOSLINK’) as the format for the Track16’s
optical input and output. Choose the format that
matches the device connected. If you are not using
the optical connections, it is recommended that
you turn them off (by choosing
Disabled from the
menu) to reduce bandwidth and processing
overhead. Note that you can operate each optical
port independently. For example, you could use the
ADAT optical format on the input (for a digital
mixer) and optical S/PDIF on the output (for a
DAT deck).
Main Out Assign
Choose Main Outs from the Main Out Assign menu
to treat the Main Outs as their own independent
output pair. Choose any other output pair to cause
the MAIN OUT jacks to mirror (duplicate) the
output pair you choose.
Return Assign
The Return Assign menu lets you choose any pair of
Track16 audio outputs. The audio signal from this
output pair is then sent back to the computer via
the
Stereo Return 1-2 bus. This stereo return bus
from the Track16 appears in your host software
alongside all other Track16 inputs, wherever your
host software lists them.
The Track16 stereo return bus can be used for a
variety of purposes. For example, you could use it
to send a final mix being played through the
Track16 back to the computer, where you could
record it for mastering or archiving purposes.
