A P P E N D I X A : A U D I O I / O R E F E R E N C E
112
Outputs at 1x sample rates
Outputs are always listed in the same order as
follows, when operating the Track16 at 1x sample
rates (44.1 or 48 kHz):
Outputs at 2x sample rates
When operating the Track16 at a 2x sample rate
(88.2 or 96 kHz), outputs are listed as follows:
Outputs at 4x sample rates
When operating the Track16 at a 4x sample rate
(176.4 or 192 kHz), outputs are listed as follows:
Output
44.1/48 kHz
Channels List position Comment
Main out 2 1-2 -
Phones 2 3-4 -
Line 2 5-6 -
Optical 8 ADAT
2 TOSLINK 7-14
7-8 -
Output
88.2/96 kHz
Channels List position Comment
Main out 2 1-2 -
Phones 2 3-4 -
Line 2 5-6 -
Optical 8 ADAT
2 TOSLINK 7-10
7-8 -
Output
176.4/ 192 kHz Channels
List position Comment
Main out 2 1-2 -
Phones 2 3-4 -
Line 2 5-6 -
Optical Not available - -
