APPENDIX
111
A
Audio I/O reference
OVERVIEW
The MOTU Audio drivers supply text string labels
for the Track16’s audio inputs and outputs to
clearly identify each one, but some applications do
not display these labels.
The following sections show how you can identify
each input and output in a numbered list like this.
Inputs at 1x sample rates
Inputs are always listed in the same order as
follows, when operating the Track16 at 1x sample
rates (44.1 or 48 kHz):
Inputs at 2x sample rates
When operating the Track16 at a 2x sample rate
(88.2 or 96 kHz), inputs are listed as follows:
Inputs at 4x sample rates
When operating the Track16 at a 4x sample rate
(176.4 or 192 kHz), inputs are listed as follows:
Input
44.1/48 kHz
Channels List position Comment
Mic 2 1-2 -
Guitar 2 3-4 -
Line 4 5-8 -
Stereo
return 2 9-10 See “Return Assign”
on page 44.
Reverb
return 2 11-12 See “Reverb return”
on page 44.
Optical 8 ADAT
2 TOSLINK 13-20
13-14 -
Input
88.2/96 kHz
Channels List position Comment
Mic 2 1-2 -
Guitar 2 3-4 -
Line 4 5-8 -
Stereo
return 2 9-10 See “Return Assign”
on page 44.
Reverb
return 2 11-12 See “Reverb return”
on page 44.
Optical 4 ADAT
2 TOSLINK 13-16
13-14 -
Input
176.4/192 kHz Channels
List position Comment
Mic 2 1-2 -
Guitar 2 3-4 -
Line 4 5-8 -
Stereo
return 2 9-10 See “Return
Assign” on page 44.
Reverb
return Not
available - -
Optical Not
available - -
