Analog Way SMART QUAD - Ref. SQD200 Programmer's Guide User Manual
Page 65
65
Group
Name
CmdResp Description
Read /
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
AUDIO_DELAY
AD AD Delay between audio and video
Rd/Wr 0
80
0
0 = no delay
500ms = max delay
0 = Main output
1 = Preview
output
AUDIO_AUTO_DELAY
Ae Ae
Automatic audio delay
Rd/Wr 0
1
1
0 = réglage manuel du Delay, 1 =
reglage automatique du delay
AUDIO_SDI_CHAN_LEFT
Ac Ac
ID of the Sdi channel to desembed
for left channel
Rd/Wr 0
15
0
0 = Group A – Channel 1
1 = Group A – Channel 2
2 = Group A – Channel 3
3 = Group A – Channel 4
4 = Group B – Channel 1
5 = Group B – Channel 2
6 = Group B – Channel 3
7 = Group B – Channel 4
8 = Group C – Channel 1
9 = Group C – Channel 2
10 = Group C – Channel 3
11 = Group C – Channel 4
12 = Group D – Channel 1
13 = Group D – Channel 2
14 = Group D – Channel 3
15 = Group D – Channel 4
10 = Channel 11 –
SDI 1
11 = Channel 11 –
SDI 2
12 = Channel 11 –
SDI 3
13 = Channel 12 –
SDI 4
AUDIO_SDI_CHAN_RIGHT
AC AC
ID of the Sdi channel to desembed
for right channel
Rd/Wr 0
15
1
0 = Group A – Channel 1
1 = Group A – Channel 2
2 = Group A – Channel 3
3 = Group A – Channel 4
4 = Group B – Channel 1
5 = Group B – Channel 2
6 = Group B – Channel 3
7 = Group B – Channel 4
8 = Group C – Channel 1
9 = Group C – Channel 2
10 = Group C – Channel 3
11 = Group C – Channel 4
12 = Group D – Channel 1
13 = Group D – Channel 2
14 = Group D – Channel 3
15 = Group D – Channel 4
10 = Channel 11 –
SDI 1
11 = Channel 11 –
SDI 2
12 = Channel 11 –
SDI 3
13 = Channel 12 –
SDI 4
AUDIO_DESEMBEND_LOCKED
As As
Information of audio channel
presence for SDI inputs
Rd
0
1
1
1 : Locked
10 = Channel 11 –
SDI 1
11 = Channel 11 –
SDI 2
12 = Channel 11 –
SDI 3
13 = Channel 12 –
SDI 4
RECORDING RECORDING_MODE
Rm Rm Video Output display mode
Rd/Wr 0
3
0
