55

Group

Name

CmdResp Description

Read /
Write

Min
Value

Max
value

Default
value

Values

Index #1

Index #2

ORATE

OR OR Output rate

Rd/Wr 0

12

8

0 = Custom Field Rate
1 = 23,97 Hz
2 = 24 Hz
3 = 25 Hz
4 = 29,97 Hz
5 = 30 Hz
6 = 50 Hz
7 = 59,94 Hz
8 = 60 Hz
9 = 72 Hz
10 = 75 Hz
11 = 85 Hz
12 = 100 Hz

0 = Main output
1 = Preview
output
2 = Recording
output

OSIGTYPEANALOG

OA OA Analog output type

Rd/Wr 0

3

0

0 = RGBs
1 = RGsB (SOG)
2 = RGB H&V
3 = YUV

0 = Main output
1 = Preview
output
2 = Recording
output

OSIGTYPEDIGITAL

OD OD Digital output type

Rd/Wr 0

2

0

0 = RGB 0-255 ( full scale )
1 = RGB 16-235 ( reduced scale )
2 = YUV

0 = Main output
1 = Preview
output
2 = Recording
output

OSYNCPOL

OS OS Analog output sync polarity

Rd/Wr 0

3

0

0 = negative H&V synchro
1 = Synchros H négative et V
positive
2 = Synchros H positive et V
négative
3 = Synchros H et V positives

0 = Main output
1 = Preview
output
2 = Recording
output
