Analog Way SMART QUAD - Ref. SQD200 Programmer's Guide User Manual
Page 60
60
Group
Name
CmdResp Description
Read /
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
PCAPTURE_KEYING_TYPE
PB PB Picture Keying Type
Rd/Wr 0
2
0
0 = No keying
1 = Luma Key Keying
2 = ChromaKey Keying
3 = Luma Key Keying + DSK
4 = ChromaKey Keying + DSK
PCAPTURE_KEYING_R_LEVEL
PC PC Picture Keying Level (Red or Tint) Rd/Wr 0
255
128
PCAPTURE_KEYING_G_LEVEL
PD PD Picture Keying Level (Green)
Rd/Wr 0
255
128
PCAPTURE_KEYING_B_LEVEL
PJ PJ
Picture Keying Level (Blue)
Rd/Wr 0
255
128
PCAPTURE_KEYING_TOLER
PK PK Keing Tolerance
Rd/Wr 0
255
10
PCAPTURE_KEYING_LUMA_LOW_LEVEL PP PP Minimum Luma Level
Rd/Wr 0
255
64
PCAPTURE_KEYING_LUMA_HIGH_LEVEL PY PY Maximum Luma Level
Rd/Wr 0
255
192
PCAPTURE_KEYING_INVERT
PO PO Keying Invert
Rd/Wr 0
1
0
PCAPTURE_KEYING_GRAB_ENABLE
PQ PQ Keying Grabber Activate
Rd/Wr 0
1
0
0 = Disable the grabber
1 = Enable the grabber
PCAPTURE_KEYING_GRAB_GET
PR PR
Keying update (capture and apply
new value)
Rd/Wr 0
1
0
Percent of OSCREEN_UTIL_H
PCAPTURE_KEYING_GRAB_H
PU PU Keying grabber position H
Rd/Wr 0
65535 32768 Percent of OSCREEN_UTIL_V
PCAPTURE_KEYING_GRAB_V
PV PV Keying grabber position V
Rd/Wr 0
65535 32768 Auto reset
PCAPTURE_BACK_COLOR
Pc Pc
Cutout color for picture capture
Rd/Wr 0
7
0
0 to 7
PCAPTURE_CAPTURE_TIME
Pt
Pt
Capture time for an animated logo Rd/Wr 0
100
0
0 = 0s
100 = 10s
PCAPTURE_MAX_FRAME
Pm Pm
Maximal number of frames of an
animated logo
Rd
1
255
80
1 à 255
PCAPTURE_FRAME_COUNT
PN PN
Number of frames of an animated
logo
Rd/Wr 1
255
1
PCAPTURE_REFRESH_INTERVAL
PI
PI
Time between 2 frames of an
animated logo
Rd/Wr 1
10000 56
Unit = 1ms
PCAPTURE_INDEX
PX PX ID of the picture to capture
Rd/Wr 0
15
0
0 = No Picture
1 = Logo 1
2 = Logo 2
3 = Logo 3
4 = Logo 4
5 = Logo 5
6 = Logo 6
7 = Logo 7
9 = Frame 1
10 = Frame 2
11 = Frame 3
12 = Frame 4
13 = Frame 5
14 = Frame 6
15 = Frame 7
