Group Name CmdResp Description
Read /
Write Min
Value Max
value Default
value
Values Index #1 Index #2
PE_POS_H pH pH
Layer left H position on output
screen
Rd/Wr 0 65535 32768
Unit = pixels ( 32768 = screen left
border )
0 = Current preset
1 = Next preset
2 = Previous
preset
3 = Memory
Preset 1
4 = Memory
Preset 2
5 = Memory
Preset 3
6 = Memory
Preset 4
0 = Background
Frame for output
1
1 = Background
Frame for output
2 in matrix mode
2 = Background
Layer for output 1
3 = Pip 1 Layer
for output1
Background Layer
for output 2 in
matrix mode
4 = Pip 2 Layer
for output1
5 = Pip 3 Layer
for output1 in
quadravision
mode
Pip1 Layer for
output 2 in matrix
mode
6 = Logo 1
7 = Logo 2
8 = Audio Output
1
9 = Audio Output
2
