Analog Way SMART QUAD - Ref. SQD200 Programmer's Guide User Manual
Page 6
6
Group
Name
CmdResp Description
Read /
Write
Min
Value
Max
value
Default
value
Values
Index #1
Index #2
FRAME_ALERT
Yf
Yf
Back-up input when an input loose
its signal
Rd/Wr 0
12
0
0 = No input
1 = Input1
2 = Input2
3 = Input3
4 = Input4
5 = Input5
6 = Input6
7 = Input7
9 = Input9
10 = Input10
11 = Input11
12 = Input12
TRANSPARENT_BACKGROUND
Yt
Yt
Disable the the black fiilng of the
bakgrounfd live layer
Rd/Wr 0
1
1
0 = use BLACK_FILL
1 = Disable black filling only for
background
BLACK_FILL
bF bF
Fill PIP with black depending on
the aspect ratio
Rd/Wr 0
1
0
0 = Disable black filling
1 = Enable black filling
DISABLE_ID
bI
bI
Disable Frame and Ids on the
preview output
Rd/Wr 0
1
0
STANDBY
STDBYSTATUS
wS wS Standby mode
Rd/Wr 0
1
0
0 = Normal mode
1 = Standby mode
STDBYREQUEST
wQ wQ Request for standby or wake up
Rd/Wr 0
1
0
0 = Wake up
1 = Standby
STDBYPROJ_ON
wN wN
Message to wake-up an output
display device ( 50 characters)
Rd/Wr 0
255
0
min = 0 max = 49
STDBYPROJ_OFF
wF wF
Message to send an output display
device to sleep ( 50 characters)
Rd/Wr 0
255
0
min = 0 max = 49
STDBYPROJ_RATE
wR wR
Output display device UART
speed
Rd/Wr 0
3
2
0 = 1200bauds
1 = 2400bauds
2 = 9600bauds
3 = 19200bauds
STDBYPROJ_CTRL
wC wC
Rd/Wr 0
4
0
0 = No request
1 = Wake up request
2 = Standby request
3 = Clear Wake up message
4 = Clear standby message
VERSION
VERI1
xi
xi
Byte 0 and 1 of the device ID
Rd
0
65535 0
ex : AAAA
VERI2
xj
xj
Byte 2 and 3 of the device ID
Rd
0
65535 0
ex : AAAA
VERI3
xk
xk
Byte 4 and 5 of the device ID
Rd
0
65535 0
ex : AAAA
VERI4
xl
xl
Byte 6 and 7 of the device ID
Rd
0
65535 0
ex : AAAA
